Exporting Data from Primavera P6 and Creating Histograms & S-Curves in Microsoft Excel

Managing complex projects often involves analyzing data visually to make informed decisions. One effective way to do this is by generating reports that include histograms and S-curves to showcase cumulative manpower, man-hours, and costs over time.
In this blog post, we’ll explore the importance of these visualizations and provide step-by-step instructions for exporting data from Primavera P6 and creating these charts in Microsoft Excel.

Why Use Excel in Conjunction with Primavera P6?

While Primavera P6 is a powerful project management tool, Microsoft Excel offers enhanced flexibility and functionality for creating custom reports. Here are a few reasons why Excel is ideal for generating histograms and S-curves:

• Familiarity and Ease of Use: Most users are more familiar with Excel, making it easier to manipulate data and customize reports without extensive training.
• Customization and Flexibility: Excel offers a wide range of chart types and formatting options, allowing users to tailor visualizations to meet specific needs or preferences.
• Data Integration: Excel enables users to integrate data from multiple sources, simplifying the creation of comprehensive reports that incorporate information from other tools or departments.

Step-by-Step Guide: Exporting Data from Primavera P6 to Excel

Step 1: Export Data from Primavera P6

1. Open your project schedule in Primavera P6 Professional.
2. Ensure the schedule is resource-loaded and/or cost-loaded.
3. Navigate to the Activities Tab.
4. Open the Activity Usage Spreadsheet.
5. Copy budgeted data (costs or units) from the Activity Usage Spreadsheet details form at the bottom.

Step 2: Process Data in Microsoft Excel

1. Paste the copied data into an Excel sheet.
2. Calculate the summary of data for each period using Excel’s SUM formula. For example, use =SUM(I3:AF3) in cell H3.
3. Calculate percentages for each period. For example, in cell I4, use the formula I3/$H$3 and format the cell as a percentage.
4. Create a new sheet/tab (e.g., Weekly Data Sheet) and organize columns for plan data, cumulative plan data, actual data, and cumulative actual data.
5. Copy the percentage values from the original sheet to the new sheet using formulas, e.g., =Sheet1!I4.
6. Calculate cumulative plan values by summing the previous cumulative value with the current plan value, e.g., =N15+O15.
7. Repeat the steps for actual data to calculate cumulative actual values.
8. Insert a Combo Chart with both line and column chart types.
9. Move the chart to a new sheet (e.g., Weekly Overall Curve).
10. Format the chart with labels, legends, and colors to improve clarity and presentation.
